○跟踪带通和交流电网陷波滤波器
○10nV或100fA满量程灵敏度
○动态储备高达80dB 内参考振荡器
○0.5Hz—100kHz参考频率
○四个A/D输入，两个D/A输出
○GPIB，RS—232接口
技术参数：
|
讯号通道
|
|
|
|
|
|
输入
|
|
|
电压
|
Single-ended or differential
|
|
电流
|
106 V/A
|
|
阻抗
|
|
|
电压
|
100 MΩ+25pF, AC coupled
|
|
电流
|
1 kΩ to virtual ground
|
|
全數值範圍敏感度
|
|
|
電壓
|
100 nV to 500 mV
|
|
電流
|
100fA to 0.5uA
|
|
大輸入
|
|
|
電壓
|
100 VDC, 10 VAC damage threshold, 2 Vpp saturation
|
|
電流
|
10 uA damage threshold, 1 uApp saturation
|
|
噪音
|
|
|
電壓
|
7 nV/√Hz at 1 kHz ()
|
|
電流
|
0.13 pA/ √Hz at 1 kHz ()
|
|
共模
|
|
|
範圍
|
1 Vp
|
|
Rejection
|
100dB [DC to 1kHz, degrades by 6dB/oct above 1 kHz]
|
|
增益精度
|
1% (2 Hz to 100kHz)
|
|
增益穩定度
|
200ppm/℃
|
|
訊號濾波器
|
60 Hz notch, -50dB (Q=10, adjustable from 45 Hz to 65 Hz)
|
|
|
120Hz notch, -50dB (Q=10, adjustable from 100Hz to 130 Hz)
|
|
|
Tracking band pass (Q=5). Filter adds 20dB to dynamic reserve.
|
|
動態儲備
|
LOW (20dB), 5ppm/℃ (1 uV to 500 mV sensitivity)
|
|
|
NORM (40dB), 50ppm/℃ (100 nV to 50 mV sensitivity)
|
|
|
HIGH (60dB), 500ppm/℃ (100 nV to 5 mV sensitivity)
|
|
|
|
|
參考通道
|
|
|
|
|
|
頻率
|
0.5 Hz to 100 kHz
|
|
輸入阻抗
|
1 MΩ, AC coupled
|
|
觸發
|
|
|
正弦
|
100 mV minimum, 1Vrms nominal
|
|
脈沖
|
±1V, 1 us minimum width
|
|
類型
|
Fundamental (f), 2nd harmonic (2f)
|
|
採數時間
|
25s (1 Hz ref.), 6s (10 Hz ref.), 2s (10 kHz ref.)
|
|
變化率
|
1 decade per 10s at 1 kHz
|
|
相位控制
|
90°shifts, fine shifts in 0.025°steps
|
|
相位噪音
|
0.01°rms at 1 kHz (100ms, 12dB/oct rolloff time constant)
|
|
相位漂移
|
0.1°/℃
|
|
相位誤差
|
Less than 1°above 10 Hz
|
|
正交度
|
90°±1°
|
|
|
|
|
調解器
|
|
|
|
|
|
穩定度
|
5ppm/℃ (LOW reserve)
|
|
|
50ppm/℃ (NORM reserve)
|
|
|
500ppm/℃ (HIGH reserve)
|
|
時間恆數
|
|
|
Pre
|
1 ms to 100s (6dB/octave)
|
|
Post
|
1s, 0.1s, none (6dB/octave)
|
|
補償
|
Up to 1x full scale (10x on expand)
|
|
諧波Rejection
|
-55 dB (band pass filter in)
|
|
|
|
|
輸出及接口
|
|
|
|
|
|
通道1輸出
|
X (Rcosθ), X offset, X Noise, R, R Offset, X5 (ext. D/A)
|
|
通道2輸出
|
Y (Rsinθ), Y offset, θ, Y Noise, X6 (ext. D/A)
|
|
輸出計
|
2% precision analog meter
|
|
LCD 輸出
|
4-digit LCD display shows same value as the analog meter
|
|
BNC 輸出
|
±10 V corresponds to full-scale input (<1Ω output impedance)
|
|
參考輸出
|
4-digit LCD display for reference phase or frequency
|
|
X1 至 X4
|
4 analog inputs, 13-bit, ±10.24 V
|
|
X5, x6
|
2 analog inputs, 13-bit, ±10.24 V
|
|
X 輸出
|
X (Rcosθ), ±10 V, <1Ω output impedance
|
|
Y 輸出
|
Y (Rsinθ), ±10 V, <1Ω output impedance
|
|
比例
|
Ratio output equals 10x signal output divided by the denominator of the input
|
|
內置震盪器
|
|
|
範圍
|
1 Hz to 100 kHz
|
|
精度
|
1%
|
|
穩定度
|
150 ppm/℃ (frequency)
|
|
|
500 ppm/℃ (amplitude)
|
|
失真度
|
2% THD
|
|
幅度
|
10 m Vrms, 100 mVrms, 1 Vrms
|
|
電腦接口
|
RS-232 standard, GPIB optional.
|
|
|
All instrument functions can be controlled and read through the interfaces
|
|
|
|
|
一般規格
|
|
|
|
|
|
電源
|
35W, 100/ 120/ 220/ 240 VAC, 50/60 Hz
|
|
呎吋
|
17” x 5.25” x 17” (WHD)
|
|
重量
|
16 lbs.
|
|
保修期
|
1年保修(包零件)
|
