DBS系列电脑全自动部份收集器
1. 用途
在科研、、高等院校及厂矿企业实验室等部门进行液相色谱层分析时，本仪器能自动计时、计滴、按峰分量收集层析液，从而代替手工操作，实现全自动收集，提高收集质量和工作效率。
本收集器可与我厂的DHL系列恒流泵、TH系列梯度仪配套使用，也可以单使用，配我厂的HD系列紫外检测仪可实现按峰收集。
DBS系列电脑全自动部份收集器
2. 特点
DBS系列电脑全自动部份收集器采用新型微电脑芯片，液晶屏中文显示，是一种新颖的升换代产品。该产品具有质量可靠、性能稳定、操作方便、使用范围广等特点，是一种适用于科研、、高等院校及工厂实验室的理想仪器。
DBS系列电脑全自动部份收集器
3. 主要技术指标
3.1 收集试管：DBS-100型 100支
DBS-160型 160支
3.2 每支大容量：DBS-100型 12ml
DBS-160型 5ml
3.3 定时收集范围：1秒 —9999分，任意选择
3.4 计滴收集范围：1—9999滴，任意选择
3.5 定峰收集范围：1—100mv任意选择
3.6 断电数据保存时间：10年
3.7 管号选择：DBS-100型 、末管1—100 末管≥管
DBS-160型 、末管1—160 末管≥管
3.8 计滴收集时断液报警时间：8分钟
3.9 连续工作时间：10天
3.10 实现全自动收集：外接电脑恒流泵、紫外检测仪、记录仪
3.11 电源：AC220V±10%；50Hz
DBS Series automatic part of the collection of computer 1. Use
In scientific research, health care, colleges and universities and laboratories, such as factories and mines sector layer liquid chromatography analysis, the automatic timing device, including drops, according to peak weight of the collection of liquid chromatography in order to replace the manual operation, the realization of fully automated collection to improve the quality and efficiency of the collection.
The collection of plants can be produced with my current pump DHL series, TH series supporting the use of gradiometer can be used alone with my HD series production of the UV detector can be achieved by peak collection.
DBS Series automatic part of the collection of computer 2. The characteristics of
DBS series of computer automatic device used to collect part of the new micro-computer chips, liquid crystal display screen in Chinese, is a novel product upgrading. The quality of the product with a reliable, stable performance, easy to operate, such as the use of a wide range of characteristics, is an applied scientific research, health care, universities and factories ideal laboratory equipment.
DBS Series automatic part of the collection of computer 3. The main technical indicators
3.1 to collect test-tube: DBS-100 type 100
DBS-160 type 160
3.2 the maximum capacity of each: DBS-100-based 12ml
DBS-160-type 5ml
3.3 the scope of the collection from time to time: 1 seconds -199 hours 59 minutes 59 seconds, arbitrary choice of
3.4 Scope of the collection drops 1-9999 drop, arbitrary choice of
3.5 set the scope of peak collection choose :1-100mv
3.6 power data retention time: 10 years
3.7 Select No.: DBS-100-type first, at the end of pipe ≥ 1-100 at the end of the first tube tube
Type the first DBS-160, 1-160 at the end of pipe at the end of the first tube tube ≥
3.8 when the collection of drops of liquid off alarm time: 8 minutes
3.9 hours of continuous work: 10 days
3.10 to achieve automatic collection: Computer constant external pump, UV detector, recorder
3.11 Power Supply: AC220V ± 10%; 50Hz
